Vacuum / Inert Gas Line, AIRFREE®##진공 메니폴드, 4-port
■ 전체 사이즈 : w1170×h585 mm
■ 구성
- A : 0 - 4 mm Valve(24/40 Inner Joint (2ea), 14/20 Inner Joint (2ea))
- B : Vacuum Line (#25 O-ring Joint Cap)
- C & J : Valved Gauging Port (18/9 Ball Joint)
- D : Inert Gas Line (18/9 Ball Joint, Inert Gas Source)
- E : Valved, Cross-over Line (for Evacuation of the entire system)
- F : End Cleanout (#9 O-ring Joint, w/ Stopper)
- G : Shotoff Valve (0 - 12 mm, Manifold와 Trap의 연결부위)
- H : Pre-trap (od50×h210 mm, 상/하부 연결부 35/20 Socket Joint)
- I : Isolation Valve (0 - 12 mm)
- J : Gaugeing Port (18/9 Ball Joint)
- K : Main Trap (od45×h210 mm, 상/하부 연결부 40 mm O-ring Joint)
- L : Vacuum Source 연결부 (od 22 mm)
■ Complete Set
- 4 Port Vacuum Manifold (1ea), Pre-trap & Main Trap (각 1ea),
#25 Stopper (2ea), #9 Stopper (2ea), #18 Pinch Clamp (2ea),
■ Chemglass


Cat. No Model Description Unit Price(VAT별도) 재고
V08-132-331 AF-0454-01  Vacuum manifold AIRFREE, Innert Gas Line Vacuum/Innert Gas Line 1/EA 문의 15 Day

 Spare Part
Cat. No Model Description Unit Price(VAT별도) 재고
V08-132-477 AF-0454-02  Vacuum manifold AIRFREE, SparePart for Vacuum Manifold Pre-trap Only 1/EA 소비자가 : 359,600원 15 Day
V08-132-481 AF-0454-03  Vacuum manifold AIRFREE, SparePart for Vacuum Manifold Main Trap Only 1/EA 소비자가 : 196,400원 15 Day
V08-132-485 AF-0454-04  Vacuum manifold AIRFREE, SparePart for Vacuum Manifold #25 O-ring Joint Cap Stopper 1/EA 소비자가 : 62,800원 15 Day
V08-132-489 AF-0454-05  Vacuum manifold AIRFREE, SparePart for Vacuum Manifold #9 O-ring Joint Cap Stopper 1/EA 소비자가 : 48,000원 15 Day
V08-132-905 CG-305-112  Vacuum manifold AIRFREE, SparePart for Vacuum Manifold #112 Viton O-ring (12ea/pk) 12/PK 소비자가 : 24,300원 15 Day
V08-132-913 CG-305-226  Viton O-ring #226 for #40 O-ring Joint 3/PK 소비자가 : 24,700원 15 Day
V08-132-636 CG-150-03  SUS Pinch Clamp #18 for Vacuum Manifold without Locking Device 1/EA 소비자가 : 20,600원 창고 : 3
본사 : 0
V08-132-623 CG-150-06  SUS Pinch Clamp #35 SparePart for Vacuum Manifold 1/EA 소비자가 : 38,800원 15 Day
V08-132-624 CG-150-09  S.S Pinch Clamp #65 for #40 O-ring Joint 1/EA 소비자가 : 116,400원 15 Day
V08-132-582 CG-961-01  0-4mm Stem & Control knob AIRFREE SparePart for Vacuum Manifold 1/EA 소비자가 : 84,500원 15 Day
V08-132-968 CG-961-03  Spare Part for Vacuum Manifold AIRFREE 0-12mm Stem & Control knob 1/EA 소비자가 : 95,700원 15 Day
